T40 - INS - ZIDOTECH ELECTRONICS CO., LTD

Compact & Lightweight: Optimized for easy installation and rapid deployment on carriers.
Versatile Navigation: Supports Pure Inertial, GPS-aided, Odometer-aided, and DVL-aided underwater modes.
Configurable Protocols: User-definable communication protocols and baud rates.
Robust Adaptability: Compatible with external damping mounts; withstands high-impact shocks and vibrations.
Rich Interfaces: Equipped with RS422, RS232, and more for seamless multi-device data exchange.
High Reliability: Engineered for stable, long-term operation.

Main Specifications

	Indicator	Parameters
1	Azimuth self-alignment accuracy	≤0 .5 °sec(Φ)(Φ is local latitude)
2	Horizontal Attitude Alignment Accuracy	≤0 .02 °
3	Azimuth accuracy	≤0 .1 °/h(pure inertial)	≤0 .1°( integrated navigation)
4	Horizontal attitude accuracy	≤0 .1 °/h(pure inertial)	≤0 .02 °integrated navigation)
5	Position accuracy	≤10m (GNSS integration)	≤0 .5%D(D is range )(DVLunderwater integration)
6	Velocity accuracy	≤0 .1 m/s(GNSS integration)	Not lower than DVL velocity accuracy (DVL integration)
7	Inertial navigation accuracy	≤5 nmile/h(allignment time 10 minutes)

Physical Specifications

	Index	Parameters
1	Dimensions	110mm110mm93mm
2	weight	＜1 .3kg
3	Power Supply	17 ~36V DC power supply, nominal power supply voltage 28V
4	Power Consumption	Steady-state power consumption less than15W
5	Extemal Connector	J30JM-25ZKP
6	Operation Temperature	-40℃~+60℃
7	Storage Temperature	-55℃~+80℃
8	Vibration	6 .06g(RMS),20Hz ~2000Hz
